FRIBLOK PIVOT HINGES
Code: FAC_FRIZIONE_FRIBLOK
Code
FAC_FRIZIONE_FRIBLOK
-
Brand
Giesse
-
Product
Hinges
-
Product Class
PIVOT HINGES
-
Family product
FRIBLOK PIVOT HINGE
-
Opening
Windows
-
Application Material
Aluminium
-
Pieces/meters per pack
4
Technical Characteristics
Solidly reliable by virtue of the component structures and the inclusion of a device by which the window can be held at 30° and locked at 180°. The 30° stop can be rendered inactive by fitting the polyamide insert in the relative slot. A special screw allows external adjustment of the friction force applied: the action is particularly durable and effective as the metal walls are interfaced with one another by way of a polyamide thrust washer containing a high percentage of glass fibre. Can also be supplied, to order, without the locking mechanism.
Functions
Pivot hinge for horizontally and vertically sashes turning through 180°, fashioned entirely from extruded aluminium billet using precision machining processes.
Capacity
Horizontal pivot-hinged sash Weight of sash distributed between the two pivot hinges Using the fixing screws provided, the overall weight of the pivoted sash (glazing included) can be 70/80 kg. Vertical pivot-hinged sash Weight of sash supported entirely by the bottom pivot hinge The bottom pivot hinge must be fitted with a polyamide thrust plug (code H5065010). With normal fixing, the overall weight of the pivoting window (glazing included) can be 50/60 kg.
Materials
Extruded aluminium hinge body and fixing plates Zamak clamp adjustment ring Polyamide thrust washer Screws and hinge pin of zinc-nickel plated steel.
Quote guide
Reset
| SKU | Product Name | Cross-section type | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | With plates | With screws | Check Comp. |
|---|---|---|---|---|---|---|---|---|---|---|
| 01416 | FRIBLOK PIVOT | P005 | 48.8 | 67.5 | 77 | 46 | 7.95 | Yes | No | |
| 01443 | FRIBLOK PIVOT | C001, P002 | 47 | 60 | 70 | 40 | 10.5 | No | Yes | |
| 01448 | FRIBLOK PIVOT | - | 46 | 60 | 70 | 40 | 16 | No | Yes | |
| 01449 | FRIBLOK PIVOT | C007, C008, X000 | 47 | 68 | 70 | 26 | 19.5 | No | Yes | |
| 01454 | FRIBLOK PIVOT | C001 | 48.7 | 68 | 70 | 40 | 9.5 | No | Yes | |
| 01458 | FRIBLOK PIVOT | P008 | 48.5 | 68 | 77 | 46 | 14 | Yes | No |
