FRIBLOK PIVOT
Code: 01416
Code
01416
-
Brand
Giesse
-
Product
Hinges
-
Product Class
PIVOT HINGES
-
Family product
FRIBLOK PIVOT HINGE
-
Opening
Windows
-
Application Material
Aluminium
-
Pieces/meters per pack
4
Capacity
Horizontal pivot-hinged sash Normal fixing: Using the fixing screws provided, the overall weight of the pivoted sash (glazing included) can be 70/80 kg. Reinforced fixing: Vertical pivot-hinged sash The bottom pivot hinge must be fitted with a polyamide thrust plug (code H5065010) to be ordered together with the pivot hinge. Normal fixing: With normal fixing (as specified above), the overall weight of the pivoted sash (glazing included) can be 50/60 kg. Reinforced fixing: When ordering, indicate the weight of vertically pivoted sashes (if greater than 60 kg), so that different specifications can be applied accordingly.
Materials
Viti e perno di snodo in acciaio zincato.
Quote guide
Technical specification
| Pre-assembled | No |
| COVER Hinges | No |
| A (mm) | 48.8 |
| D (mm) | 46 |
| E (mm) | 7.95 |
| Fixing with Counterplate | No |
| Fixing with Expansion dowels | No |
| Fixing with M12 screw | No |
| Flush opening | No |
| HP Hinges | No |
| Third sash | No |
| With lock | No |
| With plates | Yes |
| With screws | No |
| CLASSIC Hinges | No |
| Cross-section type | P005 |
| C (mm) | 77 |
| B (mm) | 67.5 |
