ONE-WAY MECHANISM FOR GHIBO OUT OUTWARD OPENING

Code: FAC_MOVIMENTAZIONI_GHIBO_MONODIREZIONALE_AP_ESTERNA

main product photo
Image may differ from the chosen configuration.
Code
FAC_MOVIMENTAZIONI_GHIBO_MONODIREZIONALE_AP_ESTERNA
  • Brand

    Giesse

  • Product

    Handles

  • Product Class

    INTERNAL MECHANISMS

  • Family product

    ONE-WAY MECHANISM FOR GHIBO OUTWARD OPENING

  • Opening

    Tilt and Turn, Windows, Facades

  • Application Material

    Aluminium

  • Pieces/meters per pack

    5

Technical Characteristics

Ideal for outward-opening side-hung windows (Side Hung, doorways, etc.). This device is reversible and is ready to be fitted on either right or left sashes. The depths of the mechanisms are: - 22 mm - 27 mm - 32 mm Products make a one-way stroke of 18 mm thus allowing plenty of overlap of the fastening components. It is recommended to use this mechanism in combination with fastening pawls type art. 04030K and strikers type art. 01343K. The mechanism is designed to accommodate a 7 mm square pin and to be combined with all the window handles made by GIESSE, both of aluminium and brass, with a 43 mm fixing C/C distance. The product is secured to the sash profile with screws, not supplied. It is possible to combine the mechanisms Art. 04082/04083/04084 with the Ghibo Key Out mechanism Art. 04086/04087/04088. With these products you can lock the sliding of the fastening rod via a Euro cylinder (not supplied).

Functions

The one-way Ghibo out internal mechanism is housed in the hollow section of the profile and, via a window handle, moves the rods and locking points of outward-opening side-hung windows.

Equipment

2 polyamide tubes 2 rod - mechanism connection components 2 bushings for coupling on rods with 8 mm hole

Materials

Front plate and sliding component of zinc plated steel Case, rotor and connection devices to transmit motion in silver painted zamak Tubes and bushings of black polyamide

Add to Wish List
Contact us
Reset
Grouped product items
SKUProduct NameDrawingBacksetNotesCheck Comp.
04082SINGLE-DIRECTIONAL DEVICE GHIBO OUT BS 22"Tipo AE=22 mmstroke 18 mm
04083SINGLE-DIRECTIONAL DEVICE GHIBO OUT BS 27"Tipo AE=27 mmstroke 18 mm
04084SINGLE-DIRECTIONAL DEVICE GHIBO OUT BS 32"Tipo AE =32 mmstroke 18 mm
04106SINGLE-DIR. DEVICE GHIBO KEY OUT BS 32Tipo CE =32 mmstroke 18 mm - Single rod, integrating both the mechanism and the key block
04086SINGLE-DIRECTIONAL DEVICE GHIBO KEY OUT BS 22"Tipo BE=22 mmfor art. 04082 - Compatible with standard European cylinders and Art. 04095-04096
04087SINGLE-DIRECTIONAL DEVICE GHIBO KEY OUT BS 27"Tipo BE=27 mmfor art. 04083 - Compatible with standard European cylinders and Art. 04095-04096
04088SINGLE-DIRECTIONAL DEVICE GHIBO KEY OUT BS 32"Tipo BE =32 mmfor art. 04084 - Compatible with standard European cylinders and Art. 04095-04096
04143ONE-WAY MECHANISM GHIBO OUT WITH KEY - BS 22" INOXTipo AE =22 mmstroke 18 mm
04144SINGLE-DIREC.DEV.GHIBO OUT BS27"ST.STEELTipo AE =27 mmstroke 18 mm
04145SINGLE-DIREC.DEV.GHIBO OUT BS32"ST.STEELTipo AE =32 mmstroke 18 mm
04146ONE-WAY MECHANISM GHIBO OUT WITH KEY - BS 22" INOXTipo BE =22 mmfor art. 04143 - Compatible with standard European cylinders and Art. 04095-04096
04147ONE-WAY MECHANISM GHIBO OUT WITH KEY - BS 27" INOXTipo BE =27 mmfor art. 04144 - Compatible with standard European cylinders and Art. 04095-04096
04148ONE-WAY MECHANISM GHIBO OUT WITH KEY - BS 32" INOXTipo BE =32 mmfor art. 04145 - Compatible with standard European cylinders and Art. 04095-04096
04149SINGLE-DIREC.DEV.GHIBO KEY OUT BS22"S.S.Tipo CE =22 mmstroke 18 mm - Single rod, integrating both the mechanism and the key block
04151SINGLE-DIREC.DEV.GHIBO KEY OUT BS27"S.S.Tipo CE =27 mmstroke 18 mm - Single rod, integrating both the mechanism and the key block
04152SINGLE-DIREC.DEV.GHIBO KEY OUT BS32"S.S.Tipo CE =32 mmstroke 18 mm - Single rod, integrating both the mechanism and the key block
