TECH PIVOT HINGES
Code: FAC_FRIZIONE_TECH
Code
FAC_FRIZIONE_TECH
-
Brand
Giesse
-
Product
Hinges
-
Product Class
PIVOT HINGES
-
Family product
TECH PIVOT HINGE
-
Opening
Windows
-
Application Material
Aluminium
-
Pieces/meters per pack
4
Technical Characteristics
Pivoted sash with friction-controlled opening up to 30°; gripping force selectable by turning a screw associated with both pivot hinges. The sash opens to 30°; to open further for cleaning, press the release button located on one of the two hinges. When the lever is released, the mechanism opens to 180° and will lock the sash automatically in this position to avoid unauthorized closures. To close the sash, operate the release button again. Each pair of Tech pivot hinges requires a set of fixing plates specific to the selected profile; these must be ordered separately. Each set of plates comprises 2 sash plates and 2 frame plates. The geometry of the sash-mounted plate is designed to allow the passage of closure hardware fitted to the perimeter.
Functions
Pivot hinge for horizontally and vertically sashes turning through 180°.
Capacity
Using Tech pivot hinges in combination with Giesse original plates, pivot sashes can be specified with the following maximum dimensions and weights: Horizontal pivot-hinged sash Maximum weight of sash (aluminium + glass): 120 Kg Maximum sash dimensions: height 2200 mm - width 1600 mm Vertical pivot-hinged sash Maximum weight of sash (aluminium + glass): 100 Kg Maximum sash dimensions: height 2200 mm - width 1600 mm
Materials
Male and female hinge bodies, diecast zamak painted in RAL colours Internal mechanisms made of diecast zamak Release button, black polyamide Extruded aluminium plates Stainless steel screws
Quote guide
Reset
| SKU | Product Name | Cross-section type | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | With lock | Check Comp. |
|---|---|---|---|---|---|---|---|---|---|
| 01420 | PLATES FOR TECH PIVOT | P001 | 15.8 | 9 | 69.8 | 22 | 20.7 | No | |
| 01421 | PLATES FOR TECH PIVOT | P002 | 10 | 15.8 | 69.8 | 20.7 | 20.9 | No | |
| 01422 | PLATES FOR TECH PIVOT | P003 | 12.5 | 16.25 | 69.8 | 37.7 | 38.8 | No | |
| 01424 | PLATES FOR TECH PIVOT | P005 | 11.3 | 17.5 | 69.8 | 21 | 22.5 | No | |
| 01427 | PLATES FOR TECH PIVOT | P007 | 13 | 19 | 69.8 | 20.5 | 24 | No | |
| 01428 | PLATES FOR TECH PIVOT | P008 | 10.75 | 17.5 | 69.8 | 21.5 | 22.5 | No | |
| 01429 | PLATES FOR TECH PIVOT | P009 | 11.3 | 17.5 | 69.8 | 21 | 22.5 | No | |
| 01431 | PLATES FOR TECH PIVOT | P010 | 12.5 | 18.8 | 69.8 | 22 | 22 | No | |
| 01439 | TECH PIVOT WITHOUT STOPPING | P001-P002-P003-P004-P005-P006-P007-P008-P009-P010 | - | - | - | - | - | No | |
| 01459 | TECH PIVOT WITHOUT PLATES | P001-P002-P003-P004-P005-P006-P007-P008-P009-P010 | - | - | - | - | - | Yes | |
| 01464 | PIVOT WITH STOPS WHITOUT PLATE | C015, C001 | - | - | - | - | - | Yes |
