3D HINGES

Technical Characteristics

Hinge suitable for doors subject to intensive use (use category 4* - heavy duty use). The adjustment cartridge (Giesse patent system) keeps the hinge bodies aligned whatever the position assumed following side adjustment. Specially machined fixing plates guarantee the firmest possible attachment on both sides of the profile channel. The additional reinforcement screws on the frame plate increase the slip resistance. The thrust bearing located between the two hinge bodies increases resistance of the hinge to fatigue and wear (durability grade 7* - 200,000 test cycles). Operation guaranteed up to more than 1,000,000 cycles. Adjustments in three directions with door installed: - side adjustment (±2 mm), using the adjuster grub screw in the side cartridge. The locking grub screw, which is inside the adjuster grub screw, locks the hinge in the chosen position - compression adjustment (± 0.5 mm), obtainable by turning the eccentric bush in the frame part of the hinge with special key item 03900 - height adjustment (-2/+4 mm) obtainable by means of sash lift support block (item 00570 – purchased separately), to be positioned against the top hinge sash leaf. The hinge is to be coupled to the covers for the sash hinge and frame hinge (art. 00589), can be painted and coated, sold separately. Fitting the cover on completing installation avoids damaging the visible parts of the hinge during assembly, transport and installation. * Complies with EN 1935
