SUPRA 7 - DRILLING TEMPLATE
Code: FAC_SUPRA_7_DIMA_FORATURA
Code
FAC_SUPRA_7_DIMA_FORATURA
-
Brand
Giesse
-
Product
Handles
-
Product Class
SUPRA 7 WINDOW HANDLES
-
Family product
SUPRA 7 - DRILLING TEMPLATE
-
Opening
Tilt and Turn, Windows, Facades, Sliding
-
Application Material
Aluminium
-
Pieces/meters per pack
1
Technical Characteristics
The drilling template art. 03546 can be used for Euro groove (Euro groove central gasket) or R40 inward opening systems, by applying the two supplied pins in holes "A" or "B". The drilling template art. 03547 is a universal template that can be applied to different types of systems (Sliding, Side Hung, Top Hung, Inward Swing, etc.) as it uses a 7 mm square pin, included in the supply, as reference point, to be inserted in the slot of the mechanism rotor. To improve machining precision, we recommend holding it in place using a clamp.
Functions
Drilling template for carrying out machining on the SUPRA 7 window handle.
Materials
Art. 03546: Aluminium template body, Steel bushings Art. 03547: Steel template body and square pin
