LASER ARMS
Code: FAC_BRACCIO_LASER
Code
FAC_BRACCIO_LASER
-
Brand
Giesse
-
Product
Arms
-
Product Class
ARMS FOR CURTAIN WALL/TOP HUNG/SIDE HUNG WINDOWS
-
Family product
LASER ARM
-
Opening
Facades, Windows
-
Application Material
Aluminium
-
Pieces/meters per pack
10, 6
Technical Characteristics
These limitation arms are suitable for top-hung windows. The Arm is telescopic with 5 clicks (except for art. 01951 that only has 1) that give 5 different window opening positions. The window is closed by pushing it in the maximum opening position. The use of these items is intended on top hung windows as they cannot be released and, therefore, with side hung windows, the sash would not be openable to 90° for cleaning. On request it is possible to have Laser Arms with a lower number of catches (with the same length) and for this we invite you to contact our Giesse Customer Service. For the details, please see also the table below.
Functions
Pair of telescopic arms (one right and one left) able to limit the opening of a top hung window in different positions.
Materials
See table
Quote guide
Reset
| SKU | Product Name | Cross-section type | Permitted type of opening | Applicable in combination with | no. of notches | Type of Fixing | P1 | P2 | L1 (mm) | L2 (mm) | I1 (mm) | S1 (mm) | Check Comp. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 01950 | TELESCOPIC LASER UNIT | - | Top Hung | hinges | 5 | Self - threading | 14.8 | 11.8 | 250 | 360 | 15 | 28 | |
| 01951 | ARM LASER 2 STOP | - | Top Hung | universal | 1 | Self - threading | 16 | 16 | 155 | 186 | 20.5 | 13.5 | |
| 01952 | TELESCOPIC LASER UNIT | - | Top Hung | hinges | 5 | Self - threading | 15 | 15 | 250 | 360 | 15 | 34 | |
| 01954 | TELESCOPIC LASER UNIT | - | Top Hung | hinges | 5 | Self - threading | 13.4 | 13.4 | 250 | 360 | 15 | 23 | |
| 01955 | TELESCOPIC LASER UNIT | - | Top Hung | hinges | 5 | Self - threading | 13.4 | 13.4 | 250 | 360 | 15 | 23 | |
| 01956 | TELESCOPIC LASER UNIT | C007 | Top Hung | hinges | 5 | Contrast grubscrews | - | - | 250 | 360 | - | 24 | |
| 01959 | LIMITER ARM 14"-TYPE Q | Senza canalette | Top Hung | universal | 5 | Self - threading | 16 | 16 | 250 | 360 | 23 | 13 | |
| 01960 | TELESCOPIC LASER UNIT | Senza canalette | Top Hung | universal | 5 | Self - threading | 16 | 16 | 250 | 360 | 20 | 16.5 | |
| 01961 | TELESCOPIC LASER UNIT | Senza canalette | Top Hung | universal | 5 | Self - threading | 16 | 16 | 250 | 360 | 20 | 16.5 |
